0.2N.m NEMA17 1.8° Step angle nema stepper motor 34mm length

Product Categories

Shenzhen Guanhong Automation Co., Ltd.

Contact Now

Name: 02Nm NEMA17 18 Step angle nema stepper motor 34mm length
Brand: SZGH
Price: 1 USD

Brand Name : SZGH

Model Number : 42BYGH234-408

Certification : CE

Place of Origin : Shenzhen, China

MOQ : 1 set

Price : negotiation

Payment Terms : TT in advance / Western Union / Paypal /LC/Alipay/Creditcard

Supply Ability : 300 sets per month

Delivery Time : within 3-5 days upon receipt of full payment

Packaging Details : Packaged with International Standard

Frame Size : NEMA17

Axle Diameter (mm) : 5mm

Length(mm) : 34mm

Holding Torque (N*m) : 0.2N.m

Current (A/Phase) : 0.87A

Weight(KG) : 0.23kg

Contact Now

0.2N.m NEMA17 1.8° Step angle high Precision 2 Phase Stepper Motor

Technical specification

Model	shaft diametier (mm)	motor length (mm)	Step angle (°)	Holding torque (N.m)	phase voltage (V)	phase current (A)	Phase rawistance (ohms)	Phase inductance (mH)	Rotor inertia g.cm²	weight (kg)
42BYGH448	5	34	1.8	0.2	3.12	0.87	3.1	4.6	38	0.23

0.2N.m NEMA17 1.8° Step angle nema stepper motor 34mm length
